Model No. |
YL27-G2-16W-650 |
YL27-G2-16W-1200 |
YL27-G2-32W-1200 |
YL27-G2-27W-1500 |
YL27-G2-44W-1500 |
YL27-G2-53W-1500 |
|
Size(LxWxH) |
565*60*60 |
1115*60*60 |
1115*60*60 |
1415*60*60 |
1415*60*60 |
1415*60*60 |
|
Input Voltage/Frequency |
220V-240V 50Hz/60Hz |
|||||
|
Rated Power ±10% |
16W |
16W |
32W |
27W |
44W |
53W |
|
SDCM |
＞6 |
|||||
|
Lumen Output |
1800lm |
1800lm |
3600lm |
3000lm |
5000lm |
6000lm |
|
LED Drand |
SANAN |
|||||
|
LED Type |
SMD2835 |
|||||
|
CCT |
4000/6500K |
|||||
|
CRI（Ra） |
>80 |
|||||
|
Beam angle |
120° |
|||||
|
Protection Class IEC |
Saftey Class II |
|||||
|
GLow-Wire Test(ABS housing) |
650° |
|||||
|
GLow-Wire Test(PC housing) |
850° |
|||||
|
Power Factor |
>0.9 |
|||||
|
Ambient Temperature Range |
-20℃--- +35℃ |
|||||
|
Lifetime（Hr） |
>30000h |
|||||
|
Q'ty/CTN(PCS) |
9 |
9 |
9 |
9 |
9 |
9 |
|
Inner box Size（LxWxH） |
590*63*63mm |
1140*63*63mm |
1140*63*63mm |
1440*63*63mm |
1440*63*63mm |
1440*63*63mm |
|
Carton Size（LxWxH） |
605*205*210mm |
1155*205*210mm |
1155*205*210mm |
1455*205*210mm |
1455*205*210mm |
1455*205*210mm |
